产品特性
SFP+ MSA compliant
100 GHz channel spacing
Support 9.8304 Gbps, 10.1376 Gbps, 10.3125 Gbps, and 11.32 Gbps without CDR
Wavelength auto-tuning
Up to 80 km transmission on single mode fiber
Operating case temperature: –20°C to +85°C, cold start at –40°C
48 channels (191.4–196.1 THz)
Maximum power consumption: 2.5 W
LC duplex connector
APD receiver
Single 3.3 V power supply
RoHS 2 compliant
应用场景
10G CPRI/eCPRI
10G Ethernet switches and routers
10G CPRI/eCPRI
10G Ethernet switches and routers
产品规格
|
P/N
|
|
OM6253ZX200
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach
|
Power Consumption/W
|
Temperture/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
|
SFP+
|
10G Tunable DWDM
|
LC
|
SMF
|
80 km
|
2.5
|
–20 to +85
|
0 to 4
|
–24
|
|
P/N
|
OM6253ZX200
|
|
Form Factor
|
SFP+
|
|
Transceiver
|
10G Tunable DWDM
|
|
Interface
|
LC
|
|
Media
|
SMF
|
|
Reach
|
80 km
|
|
Power Consumption/W
|
2.5
|
|
Temperture/℃
|
–20 to +85
|
|
Tx Output/dBm
|
0 to 4
|
|
Rx Input/dBm
|
–24
|
