产品特性
OSFP MSA rev5.0 compliant
IEEE 802.3df 800GBASE-VR8 standard compliant
OIF-CEI-112G-VSR-PAM4 standard compliant
8 channels full-duplex transceiver module
Maximum link length of 30 m OM3, 50 m OM4 with FEC
Maximum power dissipation ≤ 15.5 W
Single 3.3 V power supply
OSFP CMIS 5.2 Management interface compliant
IEEE 802.3ck 800GAUI-8 standard compliant
Digital diagnostic functions
850 Gbps aggregate bit rate
Single MPO-16/APC receptacle
Operating case temperature range 0°C to 70°C
RoHS 2 compliant
应用场景
800G Ethernet
Data Center Network
800G Ethernet
Data Center Network
产品规格
|
P/N
|
|
OM3887SX101
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperature/℃
|
Tx Output/dBm
|
Rx Intput/dBm
|
|
OSFP
|
VR8
|
MPO
|
MMF
|
0.05
|
15.5
|
0 to 70
|
–2.6 to +3.5
|
–4.4 to +3.5
|
|
P/N
|
OM3887SX101
|
|
Form Factor
|
OSFP
|
|
Transceiver
|
VR8
|
|
Interface
|
MPO
|
|
Media
|
MMF
|
|
Reach/km
|
0.05
|
|
Power Consumption/W
|
15.5
|
|
Temperature/℃
|
0 to 70
|
|
Tx Output/dBm
|
–2.6 to +3.5
|
|
Rx Intput/dBm
|
–4.4 to +3.5
|
