产品特性
QSFP112 MSA compliant
IEEE 802.3ck 400GAUI-4 standard compliant
CMIS 5.2 Management interface compliant
4 channels full-duplex transceiver module
Maximum link length of 30 m OM3, 50 m OM4 with FEC
Maximum power dissipation ≤ 8 W
Single 3.3 V power supply
IEEE 802.3df 400GBASE-VR4 standard compliant
OIF-CEI-112G-VSR-PAM4 standard compliant
Digital diagnostic functions
425 Gbit/s aggregate bit rate
Single MPO-12/APC receptacle
Operating case temperature range 0°C to 70°C
RoHS 2 compliant
应用场景
400G Ethernet
Data Center Network
400G Ethernet
Data Center Network
产品规格
|
P/N
|
|
OM3638SX101
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperature/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
|
QSFP112
|
VR4
|
MPO
|
MMF
|
0.05
|
8
|
0 to 70
|
–2.6 to +3.5
|
–4.4 to +3.5
|
|
P/N
|
OM3638SX101
|
|
Form Factor
|
QSFP112
|
|
Transceiver
|
VR4
|
|
Interface
|
MPO
|
|
Media
|
MMF
|
|
Reach/km
|
0.05
|
|
Power Consumption/W
|
8
|
|
Temperature/℃
|
0 to 70
|
|
Tx Output/dBm
|
–2.6 to +3.5
|
|
Rx Input/dBm
|
–4.4 to +3.5
|
