• 1x1 2.4 GHz frequency band (channels 1–14)
• PHY supporting IEEE 802.11b/g/n, MAC supporting IEEE802.11 d/e/h/i/k/v/w
• Built-in PA and LNA, integrated with TX/RX switch and balun
• Station (STA) and access point (AP) modes, up to six STA devices allowed for access as an AP
• WFA WPA, WFA WPA2 personal, and WPS2.0
• 2/3/4-line PTA solution with coexistence of BT and BLE chips
• Input voltage range: 2.3–3.6 V, I/O power voltage: 1.8 V or 3.3 V
• RF auto-calibration solution
• Low power consumption tested at the ambient temperature of 25°C:
Ultra deep sleep mode: 3 μA@3.3 V
Low power consumption tested in a shielded environment at the ambient temperature of 25°C, with the RX duration of 1 ms, and powered by the buck:
DTIM1: 1.27 mA@3.6 V
DTIM3: 0.523 mA@3.6 V
DTIM10: 0.233 mA@3.6 V

• All single-antenna data rates of IEEE802.11b/g/n
• A maximum rate of 72.2 Mbit/s@HT20 MCS7
• Standard 20 MHz bandwidth and 5 MHz/10 MHz narrow bandwidth
• STBC
• Short GI

• A-MPDU and A-MSDU
• Blk-ACK
• QoS

• High-performance 32-bit microprocessor, up to 160 MHz
• Built-in 352 KB SRAM and 288 KB ROM
• Built-in 2 MB flash memory

• 1x SDIO interface, 2x SPI interfaces, 2x I²C interfaces, 3x UART interfaces, 15x GPIO interfaces, 7x ADC inputs, 6x PWM interfaces, and 1x I²S interface (Note: These interfaces are multiplexed.)
• External main crystal frequency of 40 MHz or 24 MHz
