Hi2120
3GPP R14/15/16, featuring high integration, low power consumption, and OpenCPU
Hi2120 is a 3GPP Release 13/14/15 compliant NB-IoT SoC that can be upgraded to Release 16 for added functionality. This SoC is highly integrated, packing in the baseband, RF transceiver, power amplifier (PA), power management unit (PMU), and digital logic. Thanks to its system-level ultra-low-power design, the SoC can work in different 3GPP working modes (DRX/eDRX/PSM). It can achieve 20 μA standby power consumption and receive downlink data in minutes in real time, meeting the requirements for real-time valve closing in meter scenarios. Its RFIC operates at the 450 MHz to 2480 MHz frequency bands, allowing for integration into a multitude of devices.
Hi2120's integrated BLE 5.0 accommodates traditional local maintenance and debugging requirements – from production calibration, to local OTA update, to onsite fault locating and parameter configuration.
Hi2120 incorporates security across all aspects of the device, bolstered by its built-in independent security subsystem with hardware-based crypto engine that supports AES, SHA2, and RSA/ECC.
Hi2120's integrated BLE 5.0 accommodates traditional local maintenance and debugging requirements – from production calibration, to local OTA update, to onsite fault locating and parameter configuration.
Hi2120 incorporates security across all aspects of the device, bolstered by its built-in independent security subsystem with hardware-based crypto engine that supports AES, SHA2, and RSA/ECC.
-
3GPP Release 15/16 compliant
• Release 15/16 multi-carrier, low power consumption, and low latency features
• 3GPP frequency bands 450–2200MHz
• Integrated RF transceiver, PA, and CPUs -
Integrated OpenCPU and analog peripherals
• Multi-core processor, with powerful performance and good scalability
• Analog peripherals: temperature sensor, touch sensor, analog-to-digital converter, calibration module, and voltage comparator -
Integrated BLE 5.0
• Local maintenance and debugging: production calibration, local OTA, fault locating, and parameter configuration
• Innovative services: prepaid mobile recharge and linkage between the gas valve and alarm system -
Security core and independent security subsystem
• Hardware encryption engine, AES, SHA2, RSA/ECC
• Secure boot
• Secure update
• TLS/DTLS hardware acceleration for secure data transmission
• Secure storage isolated from applications
NB-IoT, the massive IoT connectivity to an intelligent world
NB-IoT is a leading cellular, LPWA technology developed to empower a wide range of IoT devices and services. It represents the next intelligent paradigm, endowing devices with connected attributes in a diverse array of applications such as smart home, smart mobility, smart city services. By 2020, there were more than 100 million NB-IoT connections across the globe. This number is expected to surpass the 1 billion mark in the next 5 years.
Key Features
Communications Protocols• BLE 5.0
• 3GPP Release 13/14/15 NB-IoT (supporting upgrades to Release 16) • Category NB2, 2HARQ |
RF• BLE 5.0
• Supported frequency bands: • NB-IoT: 1, 2, 3, 4, 5, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 31, 65, 66, 70, 71, 72, 73 • BLE: 2400–2483.5 MHz • Integrated industry-leading, highly efficient PA |
CPUs• 3x in-house CPUs (security CPU, application CPU, and protocol CPU), all packed with the memory protection unit (MPU)
• Configurable CPU frequency (applicable to application and protocol CPUs) |
Memory• Flash memory: 2 MB/4 MB
• RAM: 64 KB |
System• I/O voltage: 1.5 V, 1.8 V, 2.1 V, 2.7 V, 3.0 V, or 3.3 V
• Clock source: 26 MHz or 38.4 MHz crystal oscillator, with support for external 32 kHz crystal oscillators • 48-bit timer with a clock frequency of 32 kHz |
Peripherals• Up to 40x GPIOs
• Up to 4x UARTs, with configurable baud rates • 1x low-power UART capable of working in deep sleep mode • 3x PWM outputs for different modes and capable of working in deep sleep mode; 1 PWM in the always-on domain • 3x SPIs with support for master/slave mode • 1x JTAG/SWD bus • 4x I²Cs • 1x 8-channel DMA • 5x programmable analog I/Os • 2x comparators with configurable thresholds • 1x capacitive touch sensor • 1x 12-bit 5-channel ADC • 1x 10-bit DAC • 1x temperature sensor |
Energy Efficiency• PSM mode (RAM off): approximately 1 μA
• PSM mode (RAM on): approximately 2 μA • RX mode: 0.12 mA (DRX@2.56s average current) • TX mode: approximately 170 mA@23 dBm |
Security• Secure boot, secure update, secure storage, secure debugging, secure running, and secure transmission
• True random number generation • Hardware password: Advanced Encryption Standard (AES), Secure Hash Algorithm (SHA) • Hardware public key encryption (PKE): elliptic curve cryptography (ECC), Rivest-Shamir-Adleman (RSA) • OTP |
Application• OpenCPU
• IPv4, IPv6, and non-IP • User Datagram Protocol (UDP), Transmission Control Protocol (TCP) • Datagram Transport Layer Security (DTLS), DTLS+, Transport Layer Security (TLS) • Message Queuing Telemetry Transport (MQTT), Constrained Application Protocol (CoAP) • Lightweight Machine to Machine (LwM2M) • Firmware over-the-air (FOTA) |
Packaging• 6.9 mm x 5.4 mm ball grid array (BGA) package, 1.05 mm height
|
