Hi3798MV310

Hi3798MV310 is a high-performance UHD 4Kp60 SoC for IPTV and OTT STBs. It packs a quad-core 64-bit Cortex-A53 processor, a multi-core 2D/3D acceleration engine, and a wide range of peripheral interfaces, such as USB 2.0 and SDIO 3.0.

The high-powered SoC offers cutting-edge audio and video features: H.265/AVS2 4K x 2K@P60 10-bit UHD video decoding, H.265/H.264 HD video encoding, HDR video decoding and display, and Dolby and DTS audio processing.

The SoC is engineered to help customers deploy UHD 4K services, that stand out by virtue of picture quality, stream compatibility, video playback, and overall system performance.

It can well to accommodate the growing demands for such value-added services as video communications, cloud gaming, and multi-screen interaction.

4Kp60 decoding
H265/AVS2 codec
High performance CPU/GPU

Key Features

High-Performance CPU

• Quad-core 64-bit Cortex-A53
• Multimedia acceleration engine Neon
• Hardware Java acceleration
• Hardware floating-point coprocessor

3D GPU

• High-performance multi-core GPU Mali-450
• OpenGL ES 2.0/1.1, OpenVG 1.1

Memory Control Interfaces

• DDR3/3L/4, LPDDR3
- Up to 32-bit data width
• eMMC 5.0 flash
• Asynchronous/Synchronous NAND flash
- SLC/MLC components
- Up to 64-bit ECC

HiVXE 2 0 Video Decoding

• H.265/HEVC Main/Main 10 Profile@Level 5.1 High tier; 4K x 2K@60 fps
• AVS2 Main Profile (10-bit)@Level 8.2.60, up to 4K x 2K@60 fps 10-bit decoding
• H.264/AVC BP/MP/HP@Level 5.1, H.264/AVC MVC, 4K x 2K@30 fps decoding
• MPEG-1, 1080p@60 fps decoding
• MPEG-2 SP@ML, MP@HL, 1080p@60 fps decoding
• MPEG-4 SP@L0–3, ASP@L0–5, GMC, short header format, 1080p@60 fps decoding
• AVS-P16 (AVS+), 1080p@60 fps decoding

Image Decoding

• JPEG decoding, up to 64 MP
• PNG decoding, up to 64 MP

Video and Image Encoding

• H.265/HEVC MP@Level 5 Main-tier and H.264 BP/MP/HP@Level 4.1 video encoding, up to 1-channel 1080p@30 fps
• VBR or CBR mode for video encoding
• Low-delay encoding
• Multi-ROI encoding

Audio Encoding and Decoding

• MPEG L1/L2
• Dolby Digital/Dolby Digital Plus Decoder-Converter
• AAC-LC, HE-AAC V1/V2 decoding
• APE, FLAC, Ogg, AMR-NB, and AMR-WB decoding
• G.711 (u/a) audio decoding
• G.711 (u/a), AMR-NB, AMR-WB, and AAC-LC audio encoding
• HE-AAC transcoding DD (AC3)

Security Processing

• Secure boot, secure storage, secure update, and secure video channel
• ChinaDRM
• HDCP 2.2/1.4 for HDMI output

Imprex 2 0 Graphics and Display Processing

• Multiple HDR formats
• Image enhancement algorithms
• HDR-to-SDR conversion
• Hardware overlaying of multiple graphics and video inputs
• Multiple graphics layers and video layers
• Multi-order vertical and horizontal scaling of graphics and videos, stepless scaling
• Screen mirroring and video rotation
• Full-Format 3D video processing and display
• Enhanced two-dimensional engine (TDE) and hardware composer (HWC)
• Anti-aliasing, anti-flicker, image color and luminance enhancement, denoising, deinterlacing, sharpening, and luminance/chrominance/contrast/saturation adjustment
• Ultra-low-delay video processing

Audio and Video Interfaces

• PAL/NTSC standard output, forcible standard conversion
• 4:3 or 16:9 aspect ratios, forcible aspect ratio conversion, stepless scaling
• 4K@60 fps/50 fps/30 fps/25 fps, 1080p@60 fps/50 fps/30 fps/24 fps, 1080i@60 fps/50 fps, 720p/576p/576i/480p/480i outputs
• HD and SD output
• 1x channel HDMI 2.0b TX with HDCP 2.2 output, up to 4K x 2K@60 fps
• Analog video interfaces
- 1x CVBS
- 1x embedded VDAC
• Audio interfaces
- Audio-left and audio-right outputs
- S/PDIF
- 1x embedded ADAC
- 1x I2S/PCM digital audio input/output
- HDMI audio output

Peripheral Interfaces

• 3x USB 2.0 Host interfaces
• 1x 10/100 Mbps adaptive Ethernet port (embedded FE PHY)
• 2x 4-bit SDIO 3.0 interfaces
• 3x UART interfaces
• 1x IR receiver
• 1x LED and KeyPAD control interface
• 3x I²C interfaces
• Multiple groups of GPIO interfaces
• 1x built-in POR
