Hi3751V811Y

Hi3751V811Y is a great fit for high-end 4K LCOS, DLP, or LCD smart projectors, and is packed with premium features:

• Full support for parallel audio and video standards, such as AVS3, Audio Vivid, HDR Vivid, and ChinaDRM

• Powerful encoding and decoding capabilities capable of 8Kp30/4Kp120 decoding with popular decoding protocols such as AVS3, H.265, and AV1

• Big-Little multi-core architecture and 64-bit 2 x Cortex-A73 + 2 x Cortex-A53 CPUs to support high-speed computing in diverse complex home scenarios

• Mali-G51 MP4 GPU capable of 4K UI and 3D rendering

• Large bandwidth to support higher memory capacity and smoother system operations

• Algorithms that improve the clarity, color, contrast, and smoothness, including the upgraded HiSilicon-developed PQ algorithm, AI PQ algorithm, and 4K@120 Hz MEMC

• 4K@60 Hz keystone correction algorithm that delivers quality similar to that provided by hardware-based keystone correction while reducing the cost of the device

Parallel standard support

AVS3, Audio Vivid, HDR Vivid, and ChinaDRM
Optimal Projector Adaptation

Built-in 4K@60 Hz keystone correction algorithm, comparable to hardware-based keystone correction
Optimal LCD Projector Adaptation

TCON-less panel power-on for 4K LCD projectors, for reduced size of projectors
Up to 8 GB of Memory

Smoother system running

HDR Vivid

Bringing out vibrant colors

HDR Vivid is released by the UWA,and intelligently optimizes HDR schemes on a frame-by-frame basis. With dynamic metadata and tone mapping, this technology dynamically adjusts display effects based on the actual brightness and color information to deliver consistent color vibrancy and detail. HDR Vivid tweaks images to display colors and textures closer to reality, with precise contrast and distinct bright and dark regions.

Learn More

AVS3

8K/4K UHD codec with leading performance

AVS3, published in October 2021, is the next-generation UHD audio and video encoding standard designated by China's NRTA, DVB, and IEEE. AVS3 is the latest member of the family of video encoding standards developed by China's AVS Workgroup. It is capable of encoding video with approximately 40% bitrate savings for the same subjective quality compared to HEVC. This places AVS3 among the world's most efficient video encoding technologies.

Learn More

Key Features

High-Performance CPU

• Big-Little architecture, 2 x Cortex-A73 + 2 x Cortex-A53

3D GPU

• High-performance multi-core Mali-G51 MP4

Memory Control Interfaces

• DDR3/DDR4/LPDDR4 interfaces, with up to 8 GB of storage
• eMMC 5.1

Video Decoding

• AVS3/AVS2 Main Profile (10-bit)@Level 8.2.60, up to 4K x 2K@120 fps
• ITU-T H.265 Main 10 Profile@Level 5.1 High tier, up to 4K x 2K@120 fps
• VP9 Profile 2 (10-bit), 4K x 2K@60 fps
• H.264 BP/MP/HP@Level 5.0, 4K x 2K@30 fps

Projection

• Smart 4K@60 Hz keystone correction, smart autofocus

Image Decoding

• JPEG decoding, up to 64 MP

Video Encoding

• H.264 encoding, up to 1080p@30 fps

Audio Encoding and Decoding

• Multi-format audio decoding
− Dolby Digital^option, Dolby Digital Plus^option
− DTS^option, DTS-HD^option，DTS-M6^option
− MPEG L1/L2,MP3,AAC_LC,HE_AAC,HE_AACV2

Hi-Imprex VII Engines

• Hi-HDR IV processing engine
• Hi-Imprex VII resizing engine
• Hi-Imprex VII video processing engine
• Hi-Imprex VII image enhancement engine
• Hi-SuperClear VII processing engine
• 12-bit programmable gamma LUT
• Automatic 3D format detection
• 2D-to-3D conversion
• Hi-Motion IV Engine for 4K@120 Hz processing
• 3x HDMI RX inputs Hi-Motion IV Engine for 4K@120 Hz processing
• 2x S/PDIF outputs

Peripheral Interfaces

• 3x USB 2.0
• 1x USB 3.0
• 1x 100 Mbps or 10 Mbps network port
• 2x UART
