Hi3796CV300
8K+AI flagship SoC
Our flagship 8K+AI SoC, Hi3796CV300 supports 8Kp120 decoding and display and H.265, AVS3 and AV1 protocols for 8K ultra-HD TV and smart home applications. The octa-core 64-bit Arm Cortex-A73 CPU and Mali-G52 MC6 GPU and 4K UI combine to form an intelligent human-machine interface. The independent NPU is capable of powerful edge intelligent computing while the dual-core HiFi 3 high-performance audio DSP supports 3D audio decoding, audio effect processing, and intelligent audio processing. Gaming, intelligent interactions, and smart audiovisual applications are a reality thanks to flexible connection solutions.
-
8Kp120 decoding
-
High-performance CPU/GPU
-
Proprietary NPU architecture with 9 TOPS power
Key Features
High-Performance CPU• High-performance octa-core 64-bit Arm Cortex-A73
• Integrated multimedia acceleration engine Neon • Integrated hardware floating-point coprocessor |
3D GPU• High-performance multi-core GPU Mali-G52 MC6
• OpenGL ES 3.2/2.0/1.1 • Vulkan 1.2 • OpenCL 2.0 |
NPU• Independent NPU integrated with 9 TOPS Da Vinci V200 AI engine
|
DSP• Dual-core HiFi 3 audio DSP
• HiFi 3z intelligent voice wake-up DSP |
Memory Control Interfaces• DDR3/4, LPDDR4/4X
− Up to 96-bit data width • UFS 2.1 flash • eMMC flash • NAND flash • SPI NOR/SPI NAND flash |
Video Decoding: HiVXE 3.0 Engine• H.265/HEVC Main/Main 10 Profile@Level 6.2 High tier, up to 8K@120 fps decoding
• AVS3, AVS2 Main Profile (10-bit)@Level 10.2.120, up to 8K@120 fps decoding • AV1 Main Profile@Level 6.3, up to 8K@120 fps decoding • VP9 Profile 2 (10-bit)@Level 6.1, up to 8K@60 fps decoding • H.264/AVC BP/MP/HP@Level 6.1, up to 8K@60 fps decoding • VP6/8, up to 1080p@60 fps decoding • MPEG1, up to 1080p@60 fps decoding • MPEG2 SP@ML, MP@HL, up to 1080p@60 fps decoding • MPEG4 SP@L0–3, ASP@L0–5, GMC, short header format, up to 1080p@60 fps decoding • AVS/AVS+, 1080p@60 fps decoding • VC-1 SP@ML, MP@HL, AP@L0–3, up to 1080p@60 fps decoding • Real 8/9/10, up to 1080p@60 fps decoding |
Image Decoding• JPEG decoding, up to 256 megapixels
• PNG decoding, up to 64 megapixels |
Video Encoding• H.265 encoding, up to 4K@60 fps encoding
• H.264 encoding, up to 4K@60 fps encoding • VBR or CBR mode for video encoding |
Audio Encoding and Decoding• MPEG L1/L2
• MPEG4 AAC 22.2 transparent transmission • AAC-LC and HE-AAC V1/V2 decoding • APE, FLAC, Ogg, AMR-NB, and AMR-WB decoding • G.711 (u/a) audio decoding • G.711 (u/a), AMR-NB, AMR-WB, and AAC-LC audio encoding • HE-AAC transcoding DD (AC3) • Dolby Digital/Dolby Digital Plus decoder-converter • Dolby True HD decoding • Dolby MS12 • DTS HD/DTS M6 decoding • Dolby Digital/ATMOS/DTS transparent transmission |
TS Demux and PVR• Up to 16 TS inputs (optional)
• Two TS outputs (multiplexed with two TS inputs) |
Secure Processing• Trusted Execution Environment (TEE)
• Secure media path (SMP) • Secure boot • Secure update • OTP • Digital rights management (DRM) • Downloadable conditional access system (DCAS) • HDCP 2.3/1.4 protection for HDMI®* outputs |
Graphics and Display Processing: Imprex 3.0 Engine• 8Kp120 display output
• 4K user interface (UI) • Video and image super-resolution (SR) • Hardware overlaying of multiple image and video inputs • Picture-in-Picture (PiP) • Multiple HDR modes (dynamic HDR/HDR10/HLG) • HDR/SDR conversion • Color space conversion (CSC), including BT.2020, and wide color gamut (WCG) • Motion compensated deinterlacing (MCDI) and motion compensated noise reduction (MCNR) • Video noise reduction such as de-blocking (DB) or de-ring (DR) • Intelligent color management (such as intelligent skin tone optimization) • Local dynamic contrast adjustment • Chrominance, luminance, contrast, and saturation, and color temperature adjustment • Enhanced two-dimensional engine (TDE) all by hardware |
Audio/Video Interfaces• Two HDMI® TX* interfaces:
− HDMI® TX*, up to 8K@120 fps − HDMI® 2.0b TX*, up to 4K@60 fps • One 8-lane MIPI DSI TX output, up to 2560 x 1440@60 fps • Simultaneous display and output of two video interfaces from different sources • One CVBS analog video output interface • One HDMI® RX* interface, up to 8K@120 fps • Audio interfaces − One embedded audio DAC/ADC − One S/PDIF-in interface and one S/PDIF-out interface − Four I2S/PCM audio input interfaces and four I2S audio output interfaces, supporting a maximum of 32 audio outputs and 32 audio inputs − Audio input and output for HDMI® RX/TX* |
Peripheral Interfaces• Two USB 2.0 host interfaces, one of which supports the configurable host and device on software
• Two USB 3.1 host interfaces, compatible with USB 2.0 • Two SATA 3.0 interfaces • Two PCIe 3.0 interfaces • Two RGMII/RMII network ports • Two 4-bit SDIO 3.0 interfaces (optional) • Four UART interfaces • Two smart card interfaces (SCIs), supporting T0, T1, and T14 protocols • One TSIO interface • Four SPI interfaces • One IR receiver • One LED and keypad control interface • Multiple I2C interfaces • Multiple groups of GPIO interfaces |
Others• Download and running of the boot program through the serial port or USB port
• Low-power technologies such as adaptive voltage scaling (AVS), dynamic voltage and frequency scaling (DVFS), and independent power-off for non-working domains |
|
*
This design incorporates HDMl®technology. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. |
