Hi3798MV200H
4KP60 STB SoC for Chinese broadcasting
Get the full 4K experience with 4Kp60 decoding tailored for the IPTV/over-the-top (OTT) STB markets. Thanks to the powerful Arm Cortex-A53 processor and 2D/3D accelerator, it supports AVS2/H.265/VP9 4K x 2K@60 fps 10-bit ultra-HD video decoding, H.265/H.264 HD video encoding, HDR video decoding and display, and Dolby/DTS audio processing. It has multiple interfaces and is compatible with multiple operating systems, so you can offer full-4K services and the best user experience in the industry. Better pictures, compatible streaming, and smooth videos are key to growing value-added services such as video calls, karaoke, cloud gaming, and multi-screen interaction.
-
4Kp60 decoding output
-
H.265 and AVS2 decoding
-
High-performance CPU and GPU
Key Features
High-Performance CPU• Quad-core 64-bit high-performance Arm Cortex-A53 • Integrated Neon multimedia acceleration engine • Hardware Java acceleration • Integrated hardware floating-point coprocessor
|
3D GPU• Integrated high-performance multi-core Mali 450 GPU • OpenGL ES 2.0/1.1 and OpenVG 1.1
|
Memory Control Interfaces• DDR3/3L/4 SDRAM interface, maximum 32-bit data width • SPI NOR flash interface • SPI NAND flash interface • Asynchronous/Synchronous NAND flash interfaces − SLC/MLC flash memory − Maximum 64-bit ECC • eMMC 5.0 flash interface
|
Video Decoding: HiVXE 2.0 Engine• H.265/HEVC Main/Main 10 Profile@Level 5.1 High tier, maximum 4K x 2K@60 fps 10-bit decoding • H.264/AVC BP/MP/HP@Level 5.1, H.264/AVC MVC, maximum 4K x 2K@30 fps decoding • Maximum 4K x 2K@60 fps 10-bit VP9 decoding • Maximum 1080p@60 fps VP6/8 decoding • Maximum 1080p@60 fps MPEG-1 decoding • Maximum 1080p@60 fps MPEG-2 SP@ML, MP@HL decoding • MPEG-4 SP@Levels 0−3, ASP@Levels 0−5, GMC, short header format, maximum 1080p@60 fps decoding • AVS Main Profile@Level 6.0, AVS-P16 (AVS+), maximum 1080p@60 fps decoding • VC-1 SP@ML, MP@HL, AP@Levels 0−3, maximum 1080p@60 fps decoding
|
Image Decoding• JPEG decoding, maximum 64 megapixels • PNG decoding, maximum 64 megapixels
|
Video and Image Encoding• H.265 MP@Level 5 Main tier and H.264 BP/MP/HP@Level 4.2 video encoding, maximum 1 x 1080p@30 fps or 2 x 720p@30 fps encoding • VBR or CBR mode • Low-delay encoding • Encoding of multiple ROIs
|
Audio Encoding and Decoding• MPEG L1/L2 • Dolby Digital/Dolby Digital Plus decoder-converter • Dolby True HD decoding • DTS HD/DTS M6 decoding • Dolby Digital/DTS transparent transmission • Dolby ATMOS • AAC-LC and HE AAC V1/V2 decoding • APE, FLAC, Ogg, AMR-NB, and AMR-WB decoding • G.711 (u/a) audio decoding • Dolby MS11 decoding and audio effect • G.711 (u/a), AMR-NB, AMR-WB, and AAC-LC audio encoding • HE-AAC transcoding DD (AC3)
|
TS Demultiplexing PVR• Multi-channel TS processing • Various descrambling algorithms of the DVB • Recording of scrambled and non-scrambled streams
|
Security Processing• Advanced CA • Downloadable CA • TVOS security mechanism • Secure boot, storage, and upgrade • DRM and hardware watermark • HDCP 2.2/1.4 protection for HDMI outputs
|
Graphics and Display Processing: Imprex 2.0 Engine• Dolby Vision, HDR10, and HLG • Conversion from HDR to SDR • Hardware overlaying of multi-channel graphics and video inputs • Multiple graphics layers and video layers • Multi-order vertical and horizontal scaling of videos and graphics; free scaling • Screen mirroring and video rotation • Full-format 3D video processing and display • Enhanced TDE • Anti-aliasing, anti-flicker, enhancement of image colors and luminance, NR, DEI, sharpening, adjustment of luminance, chrominance, contrast, and saturation • Ultra-low-delay video processing
|
Audio/Video Interfaces• PAL, NTSC, and SECAM standard outputs, and forcible standard conversion • Aspect ratio of 4:3 or 16:9, forcible aspect ratio conversion, and free scaling • 4Kp@60 fps/50 fps/30 fps/25 fps, 1080p@60 fps/50 fps/30 fps/24 fps, 1080i@60 fps/1080i@50 fps, and 720p/576p/576i/480p/480i outputs • HD and SD outputs • One HDMI 2.0b TX with HDCP 2.2 output, maximum 4K x 2K@60 fps • Analog video interfaces − One CVBS interface − One embedded VDAC − VBI • Audio interfaces − Audio-left and audio-right outputs − S/PDIF interface − One embedded ADAC − One I2S/PCM digital audio input/output interface − HDMI audio output interface
|
Peripheral Interface• 3x USB 2.0 host ports• 2x 10/100 Mbit/s Ethernet ports, 1x FE PHY integrated• 2x 4-bit SDIO 3.0 interfaces• 3x UART interfaces• 1x SCI controller• 1x IR receiver• 1x LED and keypad control interface• 3x I2C interfaces• Multiple groups of GPIO interfaces• One embedded POR
|
Others• Various boot modes • Boot program download and execution over a serial port or USB port • Passive standby low-power design, integrated standby processor, supporting various low-power modes and less than 30 mW standby power consumption • BGA 14 mm x 14 mm (0.55 in. x 0.55 in.) package, 2-layer PCB supported
|
