产品特性
850 Gbps aggregate bit rate
802.3cu compliant
OIF-CEI-112G-VSR-PAM4 Compliant
Non-hermetic package design
Dual duplex LC connector
Single 3.3 V power supply
RoHS 2 compliant
100G Lambda MSA compliant
OIF CMIS 5.2 Management Interface compliant
OSFP MSA rev5.0 compliant
2 x CWDM4 lanes MUX/DeMUX design
Maximum power consumption 17 W
Up to 2 km transmission on single mode fibers with FEC
应用场景
800G Ethernet
Data Center Network
800G Ethernet
Data Center Network
产品规格
|
P/N
|
|
OM3877FX200 |
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperature/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
|
OSFP
|
2 x FR4
|
LC
|
SMF
|
2
|
17
|
0 to 70
|
–0.2 to +3.7
|
–4.6 to +3.7
|
|
P/N
|
OM3877FX200 |
|
Form Factor
|
OSFP
|
|
Transceiver
|
2 x FR4
|
|
Interface
|
LC
|
|
Media
|
SMF
|
|
Reach/km
|
2
|
|
Power Consumption/W
|
17
|
|
Temperature/℃
|
0 to 70
|
|
Tx Output/dBm
|
–0.2 to +3.7
|
|
Rx Input/dBm
|
–4.6 to +3.7
|
