Features
QSFP28 MSA compliant
2 LAN-WDM lanes MUX/DEMUX design
Maximum power consumption 5 W
Supports 53.125 Gbps aggregate bit rate
Operating case temperature: 0°C to 70°C
RoHS 2 compliant
Hot pluggable 38 pin electrical interface
2 x 25G electrical interface
LC duplex connector
Up to 80 km transmission on single mode fiber with KR4 FEC
Single 3.3 V power supply
Applications
50GBASE-ZR Ethernet
Telecom Networking
50GBASE-ZR Ethernet
Telecom Networking
Product Specification
|
P/N
|
|
OM9380ZS100
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperture/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
FEC
|
|
QSFP28
|
ZR2
|
LC
|
SMF
|
80
|
5
|
0 to 70
|
2.0 to 6.5
|
–28
|
Y
|
|
P/N
|
OM9380ZS100
|
|
Form Factor
|
QSFP28
|
|
Transceiver
|
ZR2
|
|
Interface
|
LC
|
|
Media
|
SMF
|
|
Reach/km
|
80
|
|
Power Consumption/W
|
5
|
|
Temperture/℃
|
0 to 70
|
|
Tx Output/dBm
|
2.0 to 6.5
|
|
Rx Input/dBm
|
–28
|
|
FEC
|
Y
|
