Features
QSFP-DD MSA rev5.0 compliant
400GE LR4-6 IEEE802.3
FLEXO ITU-T G.695 compliant
Hermetic package design
Maximum power consumption 9 W
4 x 106.25 Gbps & 4 x 111.8 Gbps aggregate bit rate
RoHS 2 compliant
100G Lambda MSA compliant
400GE LR4-10 MSA Technical Specification Rev1.0 compliant
QSFP-DD CMIS4.0 management interface compliant
8 x 53.125 Gbps and 8 x 55.905 Gbps PAM4 electrical interface (400GAUI-8)
LC duplex connector
Single 3.3 V power supply
Applications
400G Ethernet
Data Center Network
400G OTN
400G Ethernet
Data Center Network
400G OTN
Product Specification
|
P/N
|
|
OM9658LD100
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperature/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
FEC
|
|
QSFP-DD
|
LR4
|
LC
|
SMF
|
6
|
9
|
0 to 70
|
3.3 to 4.4
|
–6.8 to +4.4
|
Y
|
|
P/N
|
OM9658LD100
|
|
Form Factor
|
QSFP-DD
|
|
Transceiver
|
LR4
|
|
Interface
|
LC
|
|
Media
|
SMF
|
|
Reach/km
|
6
|
|
Power Consumption/W
|
9
|
|
Temperature/℃
|
0 to 70
|
|
Tx Output/dBm
|
3.3 to 4.4
|
|
Rx Input/dBm
|
–6.8 to +4.4
|
|
FEC
|
Y
|
