Features
QSFP28 MSA compliant
Digital diagnostic monitoring support
4 LAN-WDM lanes MUX/DEMUX design
LC duplex connector
Up to 10 km transmission on single mode fiber
Single 3.3 V power supply
Compliant to IEEE 802.3ba 100GBASE-LR4
Hot pluggable 38 pin electrical interface
4 x 25G electrical interface
Supports 103.125 Gbps bit rate
Operating case temperature: 0°C to 70°C
RoHS 2 compliant
Applications
100GBASE-LR4 100G Ethernet
Telecom Networking
Data Center Interconnect
Enterprise Networking
100GBASE-LR4 100G Ethernet
Telecom Networking
Data Center Interconnect
Enterprise Networking
Product Specification
|
P/N
|
|
OM9558LS120
OM9558LS121 |
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperture/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
FEC
|
|
QSFP28
|
LR4
|
LC
|
SMF
|
10
|
4
3.5 |
0 to 70
|
–1.3 to +4.5
|
–8.6
|
N
|
|
P/N
|
OM9558LS120
OM9558LS121 |
|
Form Factor
|
QSFP28
|
|
Transceiver
|
LR4
|
|
Interface
|
LC
|
|
Media
|
SMF
|
|
Reach/km
|
10
|
|
Power Consumption/W
|
4
3.5 |
|
Temperture/℃
|
0 to 70
|
|
Tx Output/dBm
|
–1.3 to +4.5
|
|
Rx Input/dBm
|
–8.6
|
|
FEC
|
N
|
