Features
QSFP-DD MSA compliant
IEEE 802.3cm 400GBASE-SR8 standard compliant
Digital diagnostic functions
425 Gbps aggregate bit rate
Single MPO-16/APC receptacle
Operating case temperature range 0 to 70°C
RoHS 2 compliant
QSFP-DD CMIS4.0 management interface compliant
IEEE 802.3bs 400GAUI-8 standard compliant
8-channel full-duplex transceiver module
Maximum link length of 70 m OM3, 100 m OM4 with FEC
Maximum power dissipation < 10 W
Single 3.3 V power supply
Applications
400GE Ethernet
Data Center Network
400GE Ethernet
Data Center Network
Product Specification
|
P/N
|
|
OM3680SX200
|
|
Form Factor
|
Transceiver
|
Interface
|
Media
|
Reach/km
|
Power Consumption/W
|
Temperture/℃
|
Tx Output/dBm
|
Rx Input/dBm
|
|
QSFP–DD
|
SR8
|
MPO
|
MMF
|
0.1 |
10
|
0 to 70
|
–4.5 to +3
|
Max (–6.5, SECQ – 7.9)
|
|
P/N
|
OM3680SX200
|
|
Form Factor
|
QSFP–DD
|
|
Transceiver
|
SR8
|
|
Interface
|
MPO
|
|
Media
|
MMF
|
|
Reach/km
|
0.1 |
|
Power Consumption/W
|
10
|
|
Temperture/℃
|
0 to 70
|
|
Tx Output/dBm
|
–4.5 to +3
|
|
Rx Input/dBm
|
Max (–6.5, SECQ – 7.9)
|
